Product description
Add four ports supporting three serial protocols, to easily connect serial devices to your computer through USB, with 15kV ESD protection. Add four extra COM ports to your laptop or desktop computer, quickly and easily. This USB to RS232/422/485 serial adapter lets you connect to your serial devices through an external USB port.
The versatile serial adapter converts a single USB port into four RS232/RS422/RS485 serial ports, enabling you to connect, monitor, and control a wide range of serial devices, such as sensors, barcode scanners, and LED signage. It supports four operating modes, including RS232, RS422, 4-wire and 2-wire RS485.
With its rugged IP30-rated metal hub housing, the serial adapter is built to meet the extreme demands of harsh and mission-critical environments. It provides 15 kV ESD protection, which helps to reduce downtime in industrial environments where communications lines are more prone to noise emissions or sudden spikes in voltage.
The serial adapter offers flexible mounting options, with a built-in wall-mounting bracket and included DIN rail mounting kit. It also features a screw-locking host connection plus a screw-locking USB-B connector on the included USB cable, to prevent accidental disconnections.
The serial adapter is equipped with high-speed UARTs, providing fast data rates of up to 921Kbps in RS232/422/485 operating modes.
Specifications
General
| Product code | ICUSB234854I |
| Brand | STARTECH |
| EAN | ICUSB234854I |
| Networking / Type | Serial adapter |
| Networking / Interface (Bus) Type | USB 2.0 |
| Networking / Connectivity Technology | Wired |
| Networking / Data Transfer Rate | 921.6 |
| Networking / Data Link Protocol | RS-232 |
| Networking / Data Link Protocol | RS-485 |
| Networking / Data Link Protocol | RS-485 |
| Dimensions & Weight / Width | 11.56 |
| Dimensions & Weight / Depth | 9 |
| Dimensions & Weight / Height | 2.5 |
| Dimensions & Weight / Weight | 400 |
| System Requirements / OS Required | Microsoft Windows Server 2019 |
| System Requirements / OS Required | Apple MacOS X 10.9 - 10.15 |
| System Requirements / OS Required | Apple macOS 11.0 |
| System Requirements / OS Required | Android 7.1 (Nougat) |
| System Requirements / OS Required | Apple macOS 12.0 |
| System Requirements / OS Required | Apple macOS 13.0 |
| System Requirements / OS Required | Windows 10 (32/64 bits) |
| System Requirements / OS Required | Linux 2.4.x of hoger |
| System Requirements / OS Required | VMware vSphere 6.0 update 2 |
| System Requirements / OS Required | VMware ESXi 6.7 |
| System Requirements / OS Required | Microsoft Windows Server 2016 |
| System Requirements / OS Required | Microsoft Windows Server 2019 |
| Service & Support / Type | 2-year warranty |
| Product Line | StarTech.com |
| Model | 4 Port Seriële USB Hub naar RS-232/422/485 Adapter, Industriële USB 2.0 naar DB9 Serial Converter Hub, IP30 Rated, Din Rail Monteerbaar, 15kV ESD Bescherming (ICUSB234854I) |
| Brand | StarTech.com |
| Manufacturer | StarTech.com |
| Verpakte hoeveelheid | 1 |
| Miscellaneous / TAA Compliant | Yes |
| Miscellaneous / Colour Category | Black |
