Product description
ThinkSystem SR655 is a multi-GPU optimized rack server, with support for up to 6 single-wide GPUs providing 200% more workload acceleration in AI, SDI and VDI instances. Capacity for up to 32x 2.5" low-latency NVMe drives that pairs well with the demands of low-latency, high-bandwidth storage such as clustered SAN solutions and software-defined storage. Eight PCIe Gen4 slots offer 2x faster I/O and support for 16 DIMMs with 1TB of DDR4 memory capacity ensure the SR655 is ideal for high performance database applications.
Specifications
General
| Product code | 7Z01A049EA |
| Brand | LENOVO |
| EAN | 7Z01A049EA |
| OS Provided / Type | No operating system |
| Chassis / Form Factor | Rack-mountable |
| Processor / Type | EPYC |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Processor / Manufacturer | AMD |
| Processor / Clock Speed | 2.8 |
| RAM / Technology | DDR4 SDRAM |
| RAM / Data Integrity Check | ECC |
| RAM / Features | Slots 17 - 32 are available in two-processor configuration only |
| RAM / Features | Architectuur met 8 geheugenplaatsen |
| RAM / Features | TruDDR4 |
| RAM / Features | Patrol Scrubbing |
| RAM / Features | Demand Scrubbing |
| RAM / Form Factor | DIMM 288-pin |
| Storage Removable / Type | None |
| Optical Storage / Type | None |
| Storage Controller / RAID Level | JBOD |
| Storage Controller / RAID Level | RAID 10 |
| Storage Controller / RAID Level | RAID 5 |
| Storage Controller / RAID Level | RAID 6 |
| Storage Controller / RAID Level | RAID 10 |
| Storage Controller / RAID Level | RAID 50 |
| Storage Controller / RAID Level | RAID 60 |
| Storage Controller / RAID Level | JBOD |
| Video Output / Graphics Processor | ASPEED AST2500 |
| Dimensions & Weight / Width | 44.5 |
| Dimensions & Weight / Depth | 76.5 |
| Dimensions & Weight / Height | 8.6 |
| Dimensions & Weight / Weight | 35.4 |
| Service & Support / Type | 3-year warranty |
| System / Type | Server |
| Storage Controller (2nd) / Type | Serial ATA |
| Miscellaneous / Height (Rack Units) | 2 |
| Product Line | Lenovo ThinkSystem SR655 |
| Model | 7Z01 |
| Country Kits | United Kingdom |
| Brand | Lenovo |
| Manufacturer | Lenovo |
| Verpakte hoeveelheid | 1 |
| Chassis / Manufacturer Form Factor | Rack-mountable |
| Chassis / Hot-Swap Bays Qty | 8 |
| Processor / Processor Number | 7282 |
| Processor / Number of Cores | 16-core |
| Chassis / Server Storage Bays | Hot-swap |
| Chassis / Server Swappable Drive Interface | SAS |
| Processor / Server Scalability | 1-way |
| Power Device / Power Redundancy | Optional |
| System / Hard Drive Capacity | 0 |
| Chassis / Server Swappable Drive Form Factor | 2.5" |
| Service & Support / On-Site Warranty | On-site |
| Environmental Standards / ENERGY STAR Certified | Yes |
| Chassis / Server Swappable Drive Form Factor (metric) | 6.4 cm |
| RAM / Empty Slots | 15 |
| Miscellaneous / Colour Category | Black |
| Optical Storage / Drive Type | No optical drive |
| RAM / Slots Qty | 16 |
| Hard Drive / Type | No HDD |
| Hard Drive (2nd) / Type | None |
| Display / Type | None. |
| Video Output / Graphics Processor Series | ASPEED AST |
| RAM / Installed Size | 32 |
| RAM / Max Supported Size | 1 |
