Product description
The Elo 1590L 15" open-frame LCD touch display is a great solution for kiosks, casino and amusement, self-service retail, and industrial floor automation. Featuring a slim design and narrow outside dimensions, the efficient LED backlight uses less electricity to operate and generates less heat. The 1590L provides stable, drift-free operation with outstanding image clarity and light transmission - for accurate touch responses and vivid images. The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure.
Specifications
General
| Product code | E295927 |
| Brand | ELO |
| EAN | E295927 |
| Display / Form Factor | Open frame |
| Display / Diagonal Size | 15 |
| Display / Native Resolution | 1024 x 768 |
| Display / V-Sync Rate at Max Res. | 60 |
| Display / Image Brightness | 300 |
| Display / Image Contrast Ratio | 700:1 |
| Display / Horizontal Viewing Angle | 160 |
| Display / Vertical Viewing Angle | 150 |
| Input Device / Type | Touch-screen |
| Audio Output / Type | None |
| Dimensions & Weight / Width | 33.64 |
| Dimensions & Weight / Depth | 4.19 |
| Dimensions & Weight / Height | 26.44 |
| Dimensions & Weight / Weight | 2.9 |
| Miscellaneous / Colour | Wood grain |
| Miscellaneous / Compliant Standards | CCC |
| Miscellaneous / Compliant Standards | CB |
| Miscellaneous / Compliant Standards | REACH SvHC |
| Miscellaneous / Compliant Standards | TUV Rheinland Flicker Free Certification |
| Miscellaneous / Compliant Standards | CCC |
| Miscellaneous / Compliant Standards | WEEE |
| Miscellaneous / Compliant Standards | IP65 |
| Miscellaneous / Compliant Standards | EAC |
| Miscellaneous / Compliant Standards | China RoHS |
| Miscellaneous / Compliant Standards | GEMS |
| Miscellaneous / Compliant Standards | CoC |
| Miscellaneous / Compliant Standards | IK07 |
| Miscellaneous / Compliant Standards | cUL |
| Miscellaneous / Compliant Standards | TUV |
| Miscellaneous / Compliant Standards | VCCI |
| Miscellaneous / Compliant Standards | BSMI |
| Miscellaneous / Compliant Standards | cUL |
| Miscellaneous / Compliant Standards | UL 60950 |
| Miscellaneous / Compliant Standards | CB |
| Miscellaneous / Compliant Standards | CCC |
| Service & Support / Type | 3-year warranty |
| Product Line | Elo |
| Model | 1590L |
| Country Kits | Worldwide |
| Brand | Elo |
| Manufacturer | Elo Touch Solutions |
| Verpakte hoeveelheid | 1 |
| Dimensions & Weight (Shipping) / Shipping Width | 43.4 |
| Dimensions & Weight (Shipping) / Shipping Depth | 17.5 |
| Dimensions & Weight (Shipping) / Shipping Height | 37.5 |
| Dimensions & Weight (Shipping) / Shipping Weight | 4.7 |
| Display / Response Time | 23 |
| Display / Interface | DisplayPort |
| Display / Interface | DisplayPort |
| Display / Interface | USB-C |
| TV Tuner / TV Tuner Presence | No |
| Display / Diagonal Size (metric) | 38.1 |
| Display / LCD Backlight Technology | LED backlight |
| Display / Colour Support | 16.2 million colours |
| Miscellaneous / Colour Category | Brown |
| Display / Type | LED-backlit LCD monitor |
| Display / Touchscreen | Yes |
