Product description
The Elo 2494L 23.8-inch open-frame touch display features a thin and compact state-of-the-art design, with energy-saving and low-heat LED panels. Available with IntelliTouch (SAW) or TouchPro (PCAP) touch technologies, the 2494L offers the versatility needed for commercial kiosk applications from industrial automation and gaming to self-service and retail.
Featuring a brilliant wide viewing angle panel, Elo's open frames can be mounted in landscape, portrait, and face-up orientations providing optimal flexibility for integrating in any table, kiosk, or cabinet design. With proven Elo expertise and reliability built in, the industrial-grade displays provide outstanding image clarity and light transmissivity as well as stable, drift-free operation for accurate touch responses.
Specifications
General
| Product code | E493782 |
| Brand | ELO |
| EAN | E493782 |
| Display / Form Factor | Open frame |
| Display / Diagonal Size | 23.8 |
| Display / Native Resolution | 1920 x 1080 |
| Display / V-Sync Rate at Max Res. | 60 |
| Display / Image Brightness | 250 |
| Display / Image Contrast Ratio | 3000:1 |
| Display / Horizontal Viewing Angle | 178 |
| Display / Vertical Viewing Angle | 178 |
| Input Device / Type | Touch-screen |
| Dimensions & Weight / Width | 56.92 |
| Dimensions & Weight / Depth | 3.8 |
| Dimensions & Weight / Height | 34.11 |
| Dimensions & Weight / Weight | 6.17 |
| Miscellaneous / Colour | Wood grain |
| Miscellaneous / Compliant Standards | CCC |
| Miscellaneous / Compliant Standards | CB |
| Miscellaneous / Compliant Standards | TUV Rheinland Flicker Free Certification |
| Miscellaneous / Compliant Standards | CCC |
| Miscellaneous / Compliant Standards | WEEE |
| Miscellaneous / Compliant Standards | China RoHS |
| Miscellaneous / Compliant Standards | GEMS |
| Miscellaneous / Compliant Standards | CoC |
| Miscellaneous / Compliant Standards | IK07 |
| Miscellaneous / Compliant Standards | cUL |
| Miscellaneous / Compliant Standards | TUV |
| Miscellaneous / Compliant Standards | VCCI |
| Miscellaneous / Compliant Standards | BSMI |
| Miscellaneous / Compliant Standards | cUL |
| Miscellaneous / Compliant Standards | DisplayPort 1.1a |
| Miscellaneous / Compliant Standards | UL 60950 |
| Miscellaneous / Compliant Standards | CB |
| Miscellaneous / Compliant Standards | CCC |
| Service & Support / Type | 3-year warranty |
| Product Line | Elo |
| Model | 2494L |
| Brand | Elo |
| Manufacturer | Elo Touch Solutions |
| Verpakte hoeveelheid | 1 |
| Dimensions & Weight (Shipping) / Shipping Width | 69.2 |
| Dimensions & Weight (Shipping) / Shipping Depth | 19 |
| Dimensions & Weight (Shipping) / Shipping Height | 45.2 |
| Dimensions & Weight (Shipping) / Shipping Weight | 8.07 |
| Display / Response Time | 16 |
| Display / Interface | DisplayPort |
| Display / Interface | DisplayPort |
| Display / Interface | USB-C |
| TV Tuner / TV Tuner Presence | No |
| Display / Diagonal Size (metric) | 60.5 |
| Display / LCD Backlight Technology | LED backlight |
| Display / Colour Support | 16.7 million colours |
| Miscellaneous / Colour Category | Brown |
| Display / Type | LED-backlit LCD monitor |
| Display / Touchscreen | Yes (10-point multi-touch) |
| Display / Video Format | Full HD (1080p) |
