Product description
The 2201L offers a flexible, space-saving design, HD wide-aspect ratio 22-inch LCD touch monitor. Well-suited to meet durability as well as aesthetic requirements for front-of-store, back office, kiosk and even out-of-store applications, the Elo Touch Solutions 2201L offers real versatility for a variety of retail and hospitality interactive solutions.
The 2201L with iTouch surface acoustic wave (SAW) touchscreen technology provides stable "drift-free" operation with outstanding image clarity, resolution, and light transmission - for an accurate touch response. Wide-screen format displays allow extra content on the screen and are quickly becoming preferred in corporate environments for publishing and dual window applications, and are popular in public venue environments due to a high-definition cinematic-like experience.
Specifications
General
| Product code | E382790 |
| Brand | ELO |
| EAN | E382790 |
| Display / Form Factor | Desktop |
| Display / Diagonal Size | 22 |
| Display / Native Resolution | 1920 x 1080 |
| Display / V-Sync Rate at Max Res. | 60 |
| Display / Image Brightness | 250 |
| Display / Image Contrast Ratio | 1000:1 |
| Display / Horizontal Viewing Angle | 178 |
| Display / Vertical Viewing Angle | 178 |
| Input Device / Type | Touch-screen |
| Audio Output / Type | Speaker(s) |
| Dimensions & Weight / Width | 55.1 |
| Dimensions & Weight / Depth | 19.3 |
| Dimensions & Weight / Height | 39.2 |
| Dimensions & Weight / Weight | 7.5 |
| Miscellaneous / Colour | Black |
| Miscellaneous / Compliant Standards | CCC |
| Miscellaneous / Compliant Standards | CB |
| Miscellaneous / Compliant Standards | TUV Rheinland Flicker Free Certification |
| Miscellaneous / Compliant Standards | CCC |
| Miscellaneous / Compliant Standards | WEEE |
| Miscellaneous / Compliant Standards | E-Standby |
| Miscellaneous / Compliant Standards | EAC |
| Miscellaneous / Compliant Standards | China RoHS |
| Miscellaneous / Compliant Standards | GEMS |
| Miscellaneous / Compliant Standards | cUL |
| Miscellaneous / Compliant Standards | VCCI |
| Miscellaneous / Compliant Standards | BSMI |
| Miscellaneous / Compliant Standards | cUL |
| Miscellaneous / Compliant Standards | IMERC |
| Miscellaneous / Compliant Standards | Mexico CoC |
| Miscellaneous / Compliant Standards | CB |
| Miscellaneous / Compliant Standards | CCC |
| Service & Support / Type | 3-year warranty |
| Product Line | Elo |
| Model | 2201L |
| Country Kits | Worldwide |
| Brand | Elo |
| Manufacturer | Elo Touch Solutions |
| Verpakte hoeveelheid | 1 |
| Dimensions & Weight (Shipping) / Shipping Width | 52 |
| Dimensions & Weight (Shipping) / Shipping Depth | 28 |
| Dimensions & Weight (Shipping) / Shipping Height | 69 |
| Dimensions & Weight (Shipping) / Shipping Weight | 12.5 |
| Display / Response Time | 14 |
| Display / Interface | DisplayPort |
| Display / Interface | DisplayPort |
| Power / Energy Class | Class F |
| Display / Display Position Adjustments | Tilt |
| TV Tuner / TV Tuner Presence | No |
| Display / Diagonal Size (metric) | 55.9 |
| Display / LCD Backlight Technology | LED backlight |
| Display / Colour Support | 16.7 million colours |
| Miscellaneous / Colour Category | Black |
| Display / Type | LED-backlit LCD monitor |
| Display / Touchscreen | Yes |
| Display / Video Format | Full HD (1080p) |
